ATM Parts GRG H22NL CDM8240N Dispenser Control Board YT2.503.0441
ATM Machine Parts GRG H22NL CDM8240N Dispenser Control Board YT2.503.0441
|
Brand Name |
GRG |
|
Product name |
GRG CDM8240N Dispenser Control Board |
|
Part No. |
YT2.503.0441 |
|
Used in |
GRG H22NL |
|
Condition |
New |
|
Sample Order |
Acceptable |
|
Payment |
T/T,Western Union,Paypal accepted |
|
Package |
In carton box or package as clients' request |
|
Shipping |
DHL,UPS,FeDex,AIR,SEA |
|
Stock |
In stock |
|
Origin |
China,Guangdong |
|
Supply Ability |
100pcs each month |
YT2.503.0441 control board is the main PCB used in GRG H22N / H22NL ATMs, specifically for the CDM8240N cash dispenser module. It functions as the central controller for motors, sensors, and dispensing logic. Below is a consolidated, English‑formatted specification based on all available grounded sources.
GRG ATM Parts:
|
S.0100346 |
T_TRANSPORT_INSIDE_1ST_BELT (10X548X0.65) |
|
S.0100348 |
T_TRANSPORT_INSIDE_4TH_BELT (10X204X0.65) |
|
S.0100349 |
T_TRANSPORT_OUTSIDE_2ND_BELT_(10X564X0.65) |
|
S.0100350 |
T_TRANSPORT_INSIDE_3RD_BELT_(10X184X0.65) |
|
S.0100354 |
T_TRANSPORT_INSIDE_2ND_BELT( 10X304X0.65) |
|
S.0040414 |
E_RINGS_D7 |
|
YT8.300.342 |
T_TUB_WHEEL_SHAFT_ |
|
S.0040412 |
E_RINGS_D 5 |
|
YT8.322.094 |
TUB_WHEEL_08_16_14_BEARING |
|
S.0170216 |
BEARING_08120350 |
|
YT8.220.029 |
BUSHING_08_10 |
|
YT6.102.234 |
T_S_TES_R_BRACKET |
|
YT8.610.1475 |
S_F_HOLDER |
|
YT6.272.017 |
S_BACK_SYN_FRAME |
|
S.0100353 |
P_LONG_T_BELT_UPPER_BELT_ |
|
S.0100305 |
P_LONG_T_BELT_LOWER_BELT_ |
|
S.0100351 |
P_T_BELT_LOWER |
|
YT8.401.111 |
RC-20-tooth note feeder transition gear |
|
YT8.401.081 |
Gear-061808-boss-m1 |
|
YT8.401.086 |
Gear-082007-d bore boss-m1 |
|
YT8.401.096 |
Gear-082007-d bore boss-m1 |
|
YT8.401.098 |
Gear-083606-d bore boss-m1 |
|
YT8.381.216 |
Torsional spring L for corner assembly |
|
YT8.381.217 |
Torsional spring R for corner assembly |
|
YT8.080.402 |
NF rubber roller 1 |
|
YT8.080.338 |
NF rubber roller bracket |
|
S.0290102RS |
Cylindrical pin 2x14 |
|
S.0100386 |
Flat belt SE-N-SMV1 12X372X0.65 |
|
S.0070324 |
Emitting sensor G310 |
|
YT8.300.845 |
NF spool connecting shaft |
|
S.0040404 |
E6 split washer |
|
S.0010207RS |
Cross recessed flat head screw M4X6 |
|
YT6.363.1243 |
DC motor assembly of NF (NF stacker motor) |
|
YT6.363.721 |
Profiled assembly of upper transport plate 1 |
|
S.0080418 |
Flat connecting cable (15-core) |
|
S.0080416 |
Flat connecting cable (15-core) |
|
YT2.503.194 |
Infrared source plate |
|
YT8.080.508 |
NV lens |
|
YT6.363.711 |
Assembly of lower transport plate 1 |
|
YT8.401.091 |
Gear-132808-m1 |
|
S.0170240 |
Bearing 6-13-5F |
|
YT8.080.403 |
Main wheel assembly of thickness sensor of NV |
|
YT4.853.2500 |
LPS tension cushion PE03 solenoid |
|
YT4.853.2499 |
MPS tension cushion PE01 solenoid |
|
YT8.300.687 |
NE-magnetic valve connecting shaft |
|
YT8.080.412 |
NE rubber roller (small) |
|
YT8.080.244 |
Rubber wheel shaft sleeve |
|
YT6.363.549 |
Tension cushion assembly of upper diverter of NE |
|
YT8.401.028 |
Rubber wheel at NE entrance |
|
YT6.363.559 |
Gear assembly at NE entrance |
|
YT8.080.296 |
NE-large roller dial |
FAQ:
Q: Can I customize ATM parts according to my needs?
A: Yes, we offer customization services for certain parts (please contact us for details).
Q: What’s the condition of your product?
A: Generally original new, generic new, refurbished, tested working(used)
Q: Do your products have a warranty?
A: Yes. Each product have a warranty, normally it is 90days
Q: What shipping methods do you use?
A: DHL, FedEx, UPS, Air freight and Sea freight.
