ATM Parts Glory MultiMech Secure -Multi Denomination Dispenser

ATM Parts Glory MultiMech Secure -Multi Denomination Dispenser

Glory MultiMech Secure – Multi Denomination Dispenser

Key Features

• Dual locked cassettes: Key‑operated lockable cassettes ensure maximum security during cash replenishment and transit, suitable for unattended/remote locations.
• Smart double‑note detection: Proprietary Glory technology accurately detects overlapped notes even with heavily damaged banknotes; no mechanical adjustment needed.
• High reliability & uptime: Robust design delivers industry‑leading availability and low maintenance for global currencies.
• Compact & easy integration: Small footprint and standard interfaces enable simple integration into ATMs, kiosks, and payment terminals.
• Global currency support: Handles diverse banknote sizes and conditions worldwide.
• Compliance: Designed to meet RoHS, UL, and CE standards.

Specifications

• Dispensing speed: Up to 5 notes/second.
• Banknote dimensions: Width: 60–82 mm Length: 110–180 mm Thickness: 0.06–0.18 mm
• Max per transaction: 50 notes.
• Cassette capacity:

Upper: 150 mm stack / 1,300 notes

Lower: 192 mm stack / 1,700 notes

Reject compartment: 50 notes

• Communication: RS232C / USB (standard).
• Power: 24 V DC ±10%, max 3.5 A.
• Operating environment:

Temperature: 10–50 °C (50–122 °F)

Humidity: 10–85% RH (non‑condensing)

• Dimensions (H×W×D): 318 × 259 × 320 mm.
• Weight:

Without cassettes: 8.5 kg (18.7 lbs)

With cassettes: 15 kg (33.1 lbs).
